Fuji Altamira CX 1.1

Details
Constructed of ultra high-modulus C10 carbon with an excellent strength-to-weight ratio, the Altamira CX 1.1 is here to give you a lightweight, fast ride over muddy courses, soft sandpits, and tricky barriers. The flat top tube shape allows for easy shouldering, while an oversize downtube and chainstays increase torsional stiffness for superior pedaling efficiency. Its Press-Fit bottom bracket increases frame stiffness, reduces drivetrain flex, and maximizes power transfer. Fuji’s FC-330 full-carbon fork features a tapered steerer and 12mm thru-axle for increased rigidity and greater steering precision. Oval Concepts 935 carbon tubular wheels defy inertia, yet hold up to CX abuse, wrapped in Vittoria Terreno Mix that supply outstanding traction and buttery-smooth efficiency. SRAM’s Force 1 drivetrain efficiently turns your sweat into podium-bound speed, while flat-mount Force hydraulic disc brakes stop on command in any conditions. Carbon bars, seatpost, and saddle rails from Oval Concepts round out the top-tier spec on this no-compromise cyclocross machine.
Pedals sold separately
Specs
Frame | C10 high-modulus carbon, flat mount disc frame w/ shaped top tube for portaging, integrated tapered head tube w/ 1 1/2” lower, oversized 34.9mm round seat tube, PF30 BB shell, double water bottle mounts, oversized chainstays, carbon dropout w/ replaceable hanger |
---|---|
Fork | FC-330 Cross carbon monocoque, 12mm thru-axle w/ flat-mount disc system, tapered steerer |
Headset | FSA, 1 1/8” upper - 1 1/2” lower, integrated w/ carbon top cover |
Axles |
Front: 100 x 12mm Rear: 142 x 12mm |
Rims/Wheels | Oval Concepts 723 Disc, 700c 24/28H tubeless compatible |
Hubs | Centerlock |
Tires | Vittoria Terreno Mix, 700 x 33, 120tpi, folding, TNT tubeless ready |
Crankset | Quark Prime Carbon, Power ready |
Chainrings | 42T |
Bottom Bracket | SRAM, PF30 |
Chain | KMC X11SL Ni-Ti Plated |
Rear Derailleur | SRAM Force 1 |
Cassette/Rear Cogs | SRAM PG-1170, 11-32T |
Shifters | SRAM Force 1 DoubleTap w/ Hydraulic reservior, 11-speed |
Handlebars | Oval Concepts 910 Ergo, carbon, 31.8mm clamp, 133mm drop, 4° sweep |
Tape/Grips | Anti-Slip Silicone |
Stem | Oval Concepts 707, 3D-forged 6061 stem body, +/-7° |
Brake Levers | SRAM Force 1 DoubleTap w/ Hydraulic reservior |
Brakes | SRAM Force 1 Hydraulic, 140 / 140 rotors |
Saddle | Oval Concepts X38c with pressure relief zone, carbon rail |
Seat Post | Oval Concepts 950, carbon & alloy, 27.2mm diameter |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Graphite / 50cm | 785749142890 | 1091647450 | 4074 |
