Jamis Dragon 29

Jamis Dragon 29
  • Color: Shamrock
  • Color: Gloss Black
Please select options


If you thrive on connection to the trail, if you live for the flow of a screaming descent—Dragon 29 will take you there without the added weight and complexity of dual suspension.


Frame Reynolds 520 steel, 44mm head tube, 31.6 I.D. seat tube, internal dropper post routing, ISCG05
Fork Fox 34 Rhythm Series Float 29" w/ sweep adjust compression & lock-out, air spring compression, rebound adjust, tapered alloy steerer, 140mm travel
Headset FSA Orbit, Alloy cups
Axles Front: 110 x 15 thru-axle
Rear: 148 x 12mm thru-axle
Rims/Wheels Stan's No Tubes Flow D 29" rims, Shimano MT410 hubs, stainless spokes
Tires WTB Vigilante 29 x 2.5" Front & Trail Boss 29 x 2.4" Rear, TCS Tubeless
Crankset Race Face Ride, 32T
Bottom Bracket Race Face BSA
Chain KMC X12, 12-speed
Rear Derailleur Shimano SLX, 12-speed
Cassette/Rear Cogs Shimano M7100, 12-speed, 10-51T
Shifters Shimano SLX, 1x12-speed
Handlebars Race Face Ride, 35 x 760mm
Tape/Grips Jamis Lock-On
Stem Race Face Ride, 50mm
Brakes Shimano MT420 4-piston hydraulic disc, 180mm RT30 rotors
Pedals Sold separately
Saddle WTB Volt
Seat Post KS Rage Dropper, Southpaw remote

* Subject to change without notice.

Part Numbers

Option UPC MPN
Shamrock / 15-inch 845436079295 03-3207GN
Shamrock / 17-inch 845436079318 03-3209GN
Shamrock / 19-inch 845436079332 03-3211GN
Shamrock / 21-inch 845436079356 03-3213GN
Gloss Black / 15-inch 845436079288 03-3206BK
Gloss Black / 17-inch 845436079301 03-3208BK
Gloss Black / 19-inch 845436079325 03-3210BK
Gloss Black / 21-inch 845436079349 03-3212BK
